PANDORA portable gaming and mobile internet device



- Texas Instruments OMAP3530 processor at 600MHz (officially)

- 256MB DDR-333 SDRAM

- 512MB NAND FLASH memory

- IVA2+ audio and video processor using TI's DaVinci™ technology

(430MHz C64x DSP)

- ARM® Cortex™-A8 superscalar microprocessor core

- PowerVR SGX530 (110MHz officially)  OpenGL ES 2.0 compliant 3D hardware

- integrated Wifi 802.11b/g  (up to 18dBm output)

- integrated Bluetooth 2.0 + EDR (3Mbps) (Class 2, + 4dBm)

- 800x480 resolution  LTPS LCD with resistive touch screen, 4.3" widescreen, 16.7 million colors (300 cd/m2 brightness, 450:1 contrast ratio)

- Dual analog controllers

- Full gamepad controls plus shoulder buttons

- Dual SDHC card slots (up to 64GB of storage currently)

- headphone output up to 150mW/channel into 16 ohms, 99dB SNR (up to 24 bit/48KHz)

- TV output (composite and S-Video)

- Internal microphone plus ability to connect external microphone through headset

- Stereo line level inputs and outputs

- 43 button QWERTY and numeric keypad

- USB 2.0 OTG port (1.5/12/480Mbps) with capability to charge device

- USB 2.0 HOST port (480Mbps) capable of providing the full 500mA to attached devices (examples include USB memory, keyboard, mouse, 3G modem, GPS)

- up to two externally accessible UARTs and/or four PWM signals for hardware hacking, robot control, debugging, etc.

- un-brickable design with integrated boot loader for safe code experimentation

- Power and hold switch useful for "instant on" and key lockout to aid in media player applications on the go

- Runs on the Linux operating system (2.6.x)

- Dimensions: 140.29 x 83.48 x 29.25mm

- Weight: 320g (with 4000mAh battery)
